D-85MG Micro Digital Programmable Metal Gear Servo
Item No.
HRC36085
Discontinued
D-85MG Micro Digital Programmable Metal Gear Servo
Item No.
HRC36085
Selected Store
Product Details
Engineered with Hitec's state-of-the-art D-Series technology, this “micro but mighty” servo is an upgrade from the popular HS-5085MG. With soft-start enabled circuitry, 4096 high-resolution and a long-life potentiometer, the D85MG allows for smooth and decisive movement and accuracy. Programmable application-specific parameters provide the ultimate in maximum servo performance.Key Features
- Speed: @4.8V .17sec/60' / @6.0V .14sec/60'
- Torque: @4.8V 50oz/in / @6.0V 60oz/in
In The Box
- (1) D-85MG Micro Digital Programmable Metal Gear Servo
Quick Links
Manuals & SupportHighlights of the D-Series Servos
Product Specs
Application
50oz park flyers, 42-50oz sport planes, 2M/DLG sailplanes, 1:16 scale on-road, buggies & SC trucks, 1:16 scale power boats
Bearing
Top Ball Bearing
Bushing Or Bearing
Bearing
Connector Type
Universal
Current Draw Idle
3mA
Current Draw Stall
2,150mA
Deadband
2µs
Gear Type
Metal
Input Voltage
4.8V ~ 6.0V
Maximum Servo Speed
0.17 sec/60 deg @ 4.8V, 0.14 sec/60 deg @ 6.0V
Maximum Servo Torque
50oz/in @ 4.8V, 60oz/in @ 6.0V
Motor Type
Brushed
Product Height
1.18" (30 mm)
Product Length
1.14" (29 mm)
Product Weight
0.77oz (21.9g)
Product Width
0.51" (13 mm)
Programmable
Yes
Servo Operating Voltage
4.8 - 6.0V
Servo Size Category
Micro
Servo Type
Digital
Spline Count
24 Teeth
Water-Resistant
No
Wire Gauge
28 AWG
