HS-5070MH Micro Digital HV Ultra Torque Metal Gear Feather Servo

Item No. HRC35070
HS-5070MH Micro Digital HV Ultra Torque Metal Gear Feather Servo
HS-5070MH Micro Digital HV Ultra Torque Metal Gear Feather Servo
HS-5070MH Micro Digital HV Ultra Torque Metal Gear Feather Servo
Backorder
Brand Logo
5 out of 5 Customer Rating

HS-5070MH Micro Digital HV Ultra Torque Metal Gear Feather Servo

Item No. HRC35070
$39.99
Earn points on this item ⓘ
Back Order
Selected Store
The link to HS-5070MH Micro Digital HV Ultra Torque Metal Gear Feather Servo has been copied

Product Details

Hitec's new strong and speedy digital HS-5070MH possess the performance qualities necessary for the new class of 42-48 inch performance 3D aircraft and 450-size helicopters. Featuring Hitec’s durable metal gears, cored motors, top ball bearings and Generation 1 circuitry, these new additions to our vast servo family will have all your planes and helis flying with remarkable precision and power. The programmable HS-5070MH delivers an impressive 53 oz.-in. of torque at 7.4 volts.
Key Features
  • Speed: @4.8V .14sec/60' / @6.0V .12sec/60'
  • Torque: @4.8V 42oz/in / @6.0V 53oz/in
  • End Point Adjustments
In The Box
  • (1) HS-5070MH Micro Digital HV Ultra Torque Metal Gear Feather Servo
HS-5070MH Micro Digital HV Ultra Torque Metal Gear Feather Servo
Quick Links
Manuals & Support

Product Specifications

Current Draw Idle 3 mA
Product Width 0.45" (11 mm)
Maximum Servo Torque 42oz/in @ 6.0V, 53oz/in @ 7.4V
Current Draw Stall 1,300 mA
Motor Type Brushed
Servo Operating Voltage 6.0 - 7.4V (HV)
Programmable Yes
Servo Size Category Micro
Bearing Top Ball Bearing
Bushing Or Bearing Bearing
Gear Type Metal
Wire Gauge 28 AWG
Deadband 2µs
Input Voltage 6.0V ~ 7.4V
Product Height 1.14" (29 mm)
Servo Type Digital
Connector Type Universal
Maximum Servo Speed 0.14 sec/60 deg @ 6.0V, 0.12 sec/60 deg @ 7.4V
Product Length 0.92" (23 mm)
Application 65oz or less parkflyers, 36-41oz sport planes, 2M/DLG sailplanes, 500-750mm electric helis, 30-39 class gas helis, 1:16 scale power boats, buggies & on-road vehicles
Number of Poles 3
Product Weight 0.50oz (14.2g)
Water-Resistant No
