HS-5496MH Standard Digital HV Metal Gear Servo

Item No. HRC35496S
$39.99
Earn points on this item ⓘ
In Stock
Selected Store
The link to HS-5496MH Standard Digital HV Metal Gear Servo has been copied

Product Details

Hitec believes in developing the highest quality servos in the market at an affordable price. That philosophy stands true with the economical HS-5496MH metal gear digital sport servo. Based on the popular HS-5485HB, the HS-5496MH is the perfect match for match for sport airplanes up to 25% scale as well as sport cars and trucks. With 7.4 volt, 2-cell LiPo battery capability, The HS-5496MH delivers the power you need at a price you can feel good about! Trust your hobby to Hitec.
Key Features
  • Speed: @4.8V .17sec/60' / @6.0V .15sec/60'
  • Torque: @4.8V 89oz/in / @6.0V 104oz/in
In The Box
  • (1) HS-5496MH Standard Digital HV Metal Gear Servo
Needed to Complete
  • Installing in model and connecting linkage
HS-5496MH Standard Digital HV Metal Gear Servo
Quick Links
Manuals & Support

Product Specifications

Bearing Top Ball Bearing
Bushing Or Bearing Bearing
Gear Type Metal
Wire Gauge 25 AWG
Maximum Servo Torque 89oz/in @ 6.0V, 104oz/in @ 7.4V
Programmable Yes
Servo Size Category Standard
Current Draw Idle 12 mA
Product Width 0.78" (20 mm)
Deadband 4µs
Input Voltage 6.0V ~ 7.4V
Product Height 1.49" (38 mm)
Servo Type Digital
Application 50-64oz sport & scale planes, 2M & up sailplanes, 1M sailboat, 1:10 scale power boat
Product Weight 1.84oz (52.0g)
Spline Count 24 Teeth
Water-Resistant No
Connector Type Universal
Maximum Servo Speed 0.17 sec/60 deg @ 6.0V, 0.15 sec/60 deg @ 7.4V
Product Length 1.57" (40 mm)
Current Draw Stall 1,400 mA
Motor Type Brushed
Servo Operating Voltage 6.0 - 7.4V (HV)
