Product Details

Considered one of the most powerful servos in the micro class, the HS-65 is offered with a choice of “shock resistant” Metal or “zero wear” Karbonite gears. The 65 series features a top-ball bearing for long life and positive centering, 31 ounces/inches of power at 6 volts and is an excellent choice for higher performance micro helicopters, electric park flyers, and 1/18 scale cars.
Key Features
  • Speed: @4.8V .16sec/60' / @6.0V .13sec/60'
  • Torque: @4.8V 22oz/in / @6.0V 26oz/in
  • Premium Feather Servo
  • Strong Karbonite Gears
  • Ball Bearing-Supported Output Shaft
  • High Torque and High Speed
In The Box
  • (1) HS-65HB Sub-Micro Analog Karbonite Gear Servo
HS-65HB Sub-Micro Analog Karbonite Gear Servo
Quick Links
Manuals & Support

Product Specs

Application
Small Slectric Aircraft, Cars
Product Weight
0.39oz (11.2g)
Water-Resistant
No
Connector Type
Universal
Maximum Servo Speed
0.16 sec/60 deg @ 4.8V, 0.13 sec/60 deg @ 6.0V
Product Length
0.92" (23 mm)
Deadband
5µs
Input Voltage
4.8V ~ 6.0V
Product Height
0.94" (24 mm)
Servo Type
Analog
Bearing
Top Ball Bearing
Bushing Or Bearing
Bearing
Gear Type
Karbonite
Wire Gauge
28 AWG
Programmable
No
Servo Size Category
Sub-Micro
Current Draw Stall
1,200 mA
Motor Type
Brushed
Servo Operating Voltage
4.8 - 6.0V
Maximum Servo Torque
22oz/in @ 4.8V, 26oz/in @ 6.0V
Current Draw Idle
7.7 mA
Product Width
0.45" (11 mm)
