HS-65MG Sub-Micro Analog Metal Gear Servo

Item No. HRC32065S
HS-65MG Sub-Micro Analog Metal Gear Servo
HS-65MG Sub-Micro Analog Metal Gear Servo
HS-65MG Sub-Micro Analog Metal Gear Servo
HS-65MG Sub-Micro Analog Metal Gear Servo
Brand Logo
5 out of 5 Customer Rating

HS-65MG Sub-Micro Analog Metal Gear Servo

Item No. HRC32065S
$32.99
Earn points on this item ⓘ
In Stock
Selected Store
The link to HS-65MG Sub-Micro Analog Metal Gear Servo has been copied

Product Details

Considered one of the most powerful servos in the micro class, the HS-65 is offered with a choice of “shock resistant” Metal or “zero wear” Karbonite gears. The 65 series features a top-ball bearing for long life and positive centering, 31 ounces/inches of power at 6 volts and is an excellent choice for higher performance micro helicopters, electric park flyers, and 1/18 scale cars.
Key Features
  • Speed: @4.8V .14sec/60' / @6.0V .11sec/60'
  • Torque: @4.8V 25.0oz/in / @6.0V 30.55oz/in
  • Top Selling Metal Gear Feather Servo
  • High Performance Three-Pole Motor
  • Rugged Metal Gear for Added Durability
  • Ball Bearing-Supported Output Shaft
In The Box
  • (1) HS-65MG Sub-Micro Analog Metal Gear Servo
HS-65MG Sub-Micro Analog Metal Gear Servo
Quick Links
Manuals & Support

Product Specifications

Maximum Servo Torque 25oz/in @ 4.8V, 31oz/in @ 6.0V
Bearing Top Ball Bearing
Bushing Or Bearing Bearing
Gear Type Metal
Wire Gauge 28 AWG
Programmable No
Servo Size Category Sub-Micro
Current Draw Idle 8 mAh
Product Width 0.45" (11 mm)
Deadband 5µs
Input Voltage 4.8V ~ 6.0V
Product Height 0.94" (24 mm)
Servo Type Analog
Application Electric Aircraft, Helicopters, Cars
Product Weight 0.42oz (11.9g)
Water-Resistant No
Current Draw Stall 1200 mAh
Motor Type Brushed
Servo Operating Voltage 4.8 - 6.0V
Connector Type Universal
Maximum Servo Speed 0.14 sec/60 deg @ 4.8V, 0.11 sec/60 deg @ 6.0V
Product Length 0.92" (23 mm)
