HS-70MG Micro Analog Ultra Torque Metal Gear Feather Servo

Item No. HRC32070
HS-70MG Micro Analog Ultra Torque Metal Gear Feather Servo
HS-70MG Micro Analog Ultra Torque Metal Gear Feather Servo
HS-70MG Micro Analog Ultra Torque Metal Gear Feather Servo
Brand Logo
5 out of 5 Customer Rating

HS-70MG Micro Analog Ultra Torque Metal Gear Feather Servo

Item No. HRC32070
$34.99
Earn points on this item ⓘ
In Stock
Selected Store
The link to HS-70MG Micro Analog Ultra Torque Metal Gear Feather Servo has been copied

Product Details

Hitec's strong and speedy analog HS-70MG possess the performance qualities necessary for the new class of 42-48 inch performance 3D aircraft and 450-size helicopters. Featuring Hitec’s durable metal gears, cored motors, top ball bearings and Generation 1 circuitry, these new additions to our vast servo family will have all your planes and helis flying with remarkable precision and power.
Key Features
  • Torque: @4.8V 33.33oz/in / @6.0V 41.66oz/in
  • Speed: @4.8V .17sec/60' / @6.0V .14sec/60'
In The Box
  • HS-70MG Micro Analog Ultra Torque Metal Gear Feather Servo
HS-70MG Micro Analog Ultra Torque Metal Gear Feather Servo
Quick Links
Manuals & Support

Product Specifications

Deadband 5µs
Input Voltage 4.8V ~ 6.0V
Product Height 1.14" (29 mm)
Servo Type Analog
Current Draw Idle 8 mA
Product Width 0.45" (11 mm)
Programmable No
Servo Size Category Micro
Application 36-41oz sport plane, 2M/DLG sailplane, 400-500mm electric heli, 30-39 class gas heli, 1:8 scale SC trucks, 1:8 scale power boats
Number of Poles 3
Product Weight 0.50 oz (14.2g)
Water-Resistant No
Current Draw Stall 1,250mA
Motor Type Brushed
Servo Operating Voltage 4.8 - 6.0V
Connector Type Universal
Maximum Servo Speed 0.17 sec/60 deg @ 4.8V, 0.14 sec/60 deg @ 6.0V
Product Length 0.92" (23 mm)
Bearing Top Ball Bearing
Bushing Or Bearing Bearing
Gear Type Metal
Wire Gauge 28 AWG
Maximum Servo Torque 33oz/in @ 4.8V, 42oz/in @ 6.0V
