S150 AC/DC Smart Charger, 1x50W
Item No.
SPMXC1070
Discontinued
S150 AC/DC Smart Charger, 1x50W
Item No.
SPMXC1070
Selected Store
Product Details
Key Features
- Recognizes unique Smart battery data for safe, easy charging
- Charges 2-4S LiPo, Lilon, LiHV, LiFe batteries 300mAh and above
- 50 watts of charging power, up to 5 amps of charge current
- Compact, easily portable design
- One-button interface and simple to understand charging indicator
In The Box
- (1) Spektrum™ S150 AC Mini Smart Charger
- (1) AC to 20V DC 3 Amp Power Supply
- (1) Product Manual
Needed to Complete
- Nothing! The Spektrum™ S150 is usable with your Smart batteries, as well as regular, compatible batteries, right out of the box.
Quick Links
Manuals & Support
Features
- Recognizes unique Smart battery data for safe, easy charging
- Charges 2-4S LiPo, Lilon, LiHV, LiFe batteries 300mAh and above
- Also charges 2-12 cell NiMH batteries (Smart Only)
- Can also be used to charge batteries without Smart technology
- 50 watts of charging power, up to 5 amps of charge current
- Compact, easily portable design
- One-button interface and simple to understand charging indicator
- Adaptable for AC power input (includes AC to 20V DC power supply)
- Quiet internal cooling fan maintains a safe, efficient operating temperature
- Accepts future Smart technology updates
Overview
With the compact S150 AC Mini Smart Charger, modelers of all experience levels can enjoy the charging advantages of innovative Spektrum™ Smart technology. This 50 watt charger brings advanced Smart charging capabilities and features to an affordable platform that features an easy-to-use, one-button interface.
When used with Spektrum Smart batteries with an IC3™ or IC5™ connector, the S150 uploads charging data from each battery's integrated memory chip. That pack-specific data helps you evaluate battery health and makes charging a snap — because the S150 can read and make the correct chemistry setting automatically. The S150 AC Mini Smart Charger is compatible with LiPo, Lilon, LiHV, and Smart NiMH battery types.
Product Specs
Amp Meter
No
Application
Battery Charger for Electric Powered RC Vehicles and Aircraft
Battery Balance Connector
JST-XH
Battery Temperature Monitoring
No
Battery Type
Smart, Non Smart
Connector Type
IC3
Cooling Method
Fan
Discharge
Yes
Input Voltage
100-240V AC
Integrated Balancing
Yes - Internal Balancer & Internal Adapter
LiPo Compatibility
4S
Low Input Voltage Protection
Yes
Maximum Charge Rate
3 to 5 Amps
Normal/Standard Charge Current
1.0 - 5.0A
Number of Cells
2-4S LiPo, LiFe LiHV, LiFe, 2-12 cell NiMH (Smart Only)
Number of Output Ports
1
Output
5A
Output Connector
IC3
Over Current Protection
Yes
Part Type
Electronics
Peak Detection
Yes
Power (watts)
50 - 99W
Power Source
AC/DC
Product Height
1.12" (28.5mm)
Product Length
2.5" (65mm)
Product Weight
2.2oz (63g)
Product Width
1.9" (49mm)
Programmable
No
Reverse Polarity Protection
Yes
Safety Timer
Yes
Selectable Charge Rate
Yes
Shape
Rectangular
Short Circuit Protection
Yes
Software Updates
Yes
Technology
Smart
Thermal Protection
Yes
USB Power out
No
Voltage Meter
No
